New Energy AC Power Wire Harness Cable for UL10269 16AWG Conductors

New Energy AC Power Wire Harness Cable for UL10269 16AWG Conductors

This AC Power Wire Harness Cable features UL10269 16AWG conductors in red, blue, yellow, and green with a standard length of 380 mm. One end is fitted with an RNBS2-4-90D ring terminal, while the opposite end connects to PV male and female terminals.

Each wire is precisely crimped and insulated to guarantee strong mechanical connections and electrical safety. The harness supports customized lengths and terminal configurations, making it adaptable to various installation environments such as EV charging piles, solar storage systems, and power control cabinets.

Built to UL standards, this wiring solution provides excellent heat resistance, insulation stability, and mechanical durability, ensuring long-term reliability in AC power transmission applications.


Specifications

Key Features:

• High Current Capacity: 16AWG wire supports stable and safe AC power transmission.
• UL10269 Certified: Meets international electrical safety and insulation standards.
• Color-Coded Design: Red, blue, yellow, and green wires simplify wiring and reduce installation errors.
• Durable Terminals: Equipped with RNBS2-4-90D and PV connectors for secure and reliable connections.
• Heat & Flame Resistance: Withstands continuous operation at up to 105°C.
• Customizable Configurations: Lengths, connectors, and materials can be tailored for specific applications.

Applications:

• EV Charging Pile Systems: Provides safe AC power connections for electric vehicle charging infrastructure.
• Control Power Supply Units: Suitable for industrial control cabinets and smart grid power modules.
• Home Energy Storage Systems: Connects inverter and battery units for residential power storage.
• Solar Power Systems: Ideal for solar inverter AC wiring and PV system connections.
• Renewable Energy Equipment: Supports distributed energy systems and hybrid energy applications.
• Factory Power Distribution Panels: Provides efficient AC wiring for automation and control networks.

Why Choose Us?
Shenzhen Smart Connection Technology Co., Ltd. was established in 2008, integrating R&D, production, processing and sales of wiring harnesses for various electrical products. We have a professional scientific and technological research and development team, advanced production and inspection equipment, modern enterprise management, and strict quality assurance system. The company's products have passed UL safety certification and are widely used in various electrical products such as portable energy storage power supplies, household energy storage power supplies, industrial and commercial energy storage power supplies, lithium batteries, and industrial control boxes for sweeping robots.

After-sale Service:

• Technical support online service provided.
• OEM available.
• Our product with test report and certification
• Our product with 3 year warranty.

Packing & Delivery:

FAQ:

1. Does it support the customization of wiring harness?

 Yes, customized color and length options are available upon request to meet the needs of different applications.

 2. Does it comply with relevant safety and certification standards?

 Yes, our wiring harnesses comply with industry standards, such as UL, CE, etc., and have passed strict safety certification.

3. How can I get more information on the technical details and customization options for these harnesses?

You can contact our sales team for more detailed information on technical details, customization options and quotations.
